The fence barriers, where you choose the security and vehicle access control, has the standards of smooth operation at high speed with intensive use with its robust engine structure and powerful reducer system. All kinds of access, such as high speed license plate recognition, ticket parking systems, have been made compatible. Installation fence barriers perform sequential movement within 6000 'with 100% duty cycle.

Technicial Specifications
Accessories
Folders
Photo Gallery

Case Dimensions	38 x 25 x 102 cm ( W x L x H )
Case Dimensions	4,5 m (maximum)
Material	Main Body: 1,5 mm powder coated steel (standard) Arm: Rectangular / Aluminum / Fence
Operating Frequency	6000+ consecutive movements supported with 100% duty cycle. Suitable for handling 10.000+ vehicle passage per day.
Rotation Control	Operation speed control parameter adjustment on PLC panel
Motor	0.55 - 0.75 KW controlled by frequency inverter.
Position Control	Inductive limit switches with pysical position adjustment for down and up positions.
Operating Temperature	-25° / +70°
Installation	Slotted external mounting plate for robust and easy installation.
