| Material | Main Body: AISI- 304 Stainless Steel Wings: 10 mm plexiglass Top cover: Black glass with 10mm tamper. |
|
| Standard Dimensions | 32 x 103 x 98 cm ( W x L x H ) |
|
| Energy / Operating Voltage | 110 - 240V AC 50/60 Hz (+/- %10) 24V DC |
|
| Control Systems | All inputs are opto-coupler protected. Controlled by dry contact or grounding input. |
|
| Movement Mechanism | Brushless DC Motor |
|
| Electronic Control Unit | PLC control unit |
|
| Flow Rate | 20 Passage / Minutes / Normally Standard |
|
| Operating Temperature | -20° C / + 68° C |
|
| IP Rating | IP 44 |
|
| Number of Passage Lanes | Double Unit |
|
| Wing Movement | Wings Retracting into Body Linear Movement System |
|
| Side Led Stripes | Passage Free - Green Passage Closed - Red Standby - Blue |
|
